Point placement and construction site layout software

Autodesk® Point Layout software is construction layout software that enables construction professionals to utilize BIM coordinate information in the field with robotic total stations. Deliver faster and more accurate layout installation directly from Autodesk® AutoCAD®, Revit®, and Navisworks® software. Import information back into the model for QA/QC and for accurate as-built model creation. Point Layout improves office-to-field and field-to-office efficiency, reduces rework, and increases productivity in the field, helping construction professionals to complete projects on time and under budget.


Autodesk Point Layout allows for direct file format compatibility with robotic total station hardware from Topcon.

Features include

Create points within models authored in AutoCAD, Revit, or Navisworks software

Use point data from the model to drive field layout with robotic instruments

Import staked points back into the original model to create an as-built model
